Manual RV Entry Steps - RADS & RASS-21
Technical Specifications
| Specification | RADS (Double Step) | RASS-21 (Single Step) |
|---|---|---|
| Operation Mode | Manual - Spring-loaded hinges | |
| Load Capacity | 440 lbs (200 kg) | |
| Installation Width | 20.75 in (527 mm) | 20.75 in (527 mm) |
| Overall Top Width | 21.81 in (554 mm) | 21.81 in (554 mm) |
| Extended Length | 29.56 in (751 mm) | 21.45 in (545 mm) |
| Step Height | 9.64 in (245 mm) | 9.64 in (245 mm) |
| Net Weight | 18.96 lbs (8.6 kg) | 10.80 lbs (4.9 kg) |
Key Features
- High-Strength Construction: Built with premium aluminum for durability and corrosion resistance.
- Smooth Operation: Spring-loaded hinges allow for easy manual opening and closing.
- Enhanced Safety: Features an anti-slip ribbed tread surface for secure footing in all weather conditions.
- Versatile Application: Suitable for RVs, caravans, motorhomes, and camper entry systems.
- Compact Design: Engineered to maximize ground clearance when folded.
General Notes: All dimensions are based on engineering drawings. Capacity rating is verified for up to 200 kg (440 lbs).
